Laptop solution

2015-06-09 15:05:03 source: BOZHI Soft

Notebook computer physical isolation solution has a single, double wiring two.
Dual wiring scheme is applied in internal and external network servers and cables have separate crewel, the terminal uses Primus BOZHI-V6.1 type external notebook isolation card.
Single wiring scheme is applied to a single network, inside and outside the network server share a set of line, the terminal BOZHI-V6.1 type external notebook isolation card, the line shall be used in conjunction with Primus BOZHI-V66-NET8 or BOZHI-V66-NET24 network line selector.
The topology graph of the double wiring network is as follows:

Single wiring network topology diagram is as follows:
